Inter-Tel AXXESS - Figure 3-73 Example of a Point-To-Multi-Devices Setup Using ISDN PRI; Figure 3-74 Example of a BRI Point-To-Multi-Devices Setup Without a Phone System

Page 3-141
Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Example of a Point-to-Multi-Devices Setup Using ISDN PRI
INSTALLATION
3
Figure 3-73. Example of a Point-to-Multi-Devices Setup Using ISDN PRI
Figure 3-74. Example of a BRI Point-to-Multi-Devices Setup
without a Phone System
ISDN Circuit
U Interface
ISDN
Video Conference Unit
ISDN
Router
BRS
Station
Port
BRU
Station
Port
BRU
Station
Port
PRI
T Interface
NT1
Analog
Telephone
Modem or
Fax
Digital Key
Station
Port
ISDN Modem
U Interface
NT1
S/T Interface
NOTE: This example shows one BRI ISDN line being shared with three ISDN devices (terminals). This is a basic
example of a station ISDN installation without a system. This is how the ISDN devices are installed without a tele-
phone system.
ISDN DEVICE 1
ISDN DEVICE 2
ISDN DEVICE 3
LOCAL
OR
ISDN PROVIDER
END POINTS
The TEIs 64, 65, 66
are provided by the
TEI 64
TEI 65
TEI 66
SERVICE POINT
CUSTOMER LOCATION
Up to eight connec-
EXCHANGE
