Old EVMC
Figure 3-82. Old EVMC
LEDs
MONITOR
CONNECTOR
KEYBOARD
CONNECTOR
PARALLEL
PORT
SERIAL
RS232-C
RS232-C
TO CPU
DB15 PCM
CONNECTOR
FLOPPY DRIVE
CONNECTOR
MAILBOX SECURITY PAL (U23)
DSPM
CONNECTOR FOR SECOND
DSPM CARD
CARD ON-LINE
OK TO REMOVE CARD
RESET
BUTTON
POWER
MOUSE
CONNECTOR
(Ports 1-4)
(Ports 5-8)
CARD
DOWN BUTTON
POWER
CONNECTOR
FLOPPY DRIVE
NOTE: For purposes of detail, this drawing does not
show the EMI shield attached to the front edge of the card.
(Not Used)
HARD DRIVE
(for 32, 64 or 200 mailboxes)
