Appendix F – Network Topology
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Port Usage Summary
110 TCP POP3
• POP3 Exchange feature for Voice
Mail products
•IVR
Voice Mail e-mail features and UM
135 TCP RPC
• Voice Mail systems using UM
features
• Messaging Application Program-
ming Interface (MAPI) and faxing
Exchange services for e-mail fea-
tures and UM
143 TCP IMAP EM (Outbound)
• Voice Mail systems using UM
features
• MAPI and faxing
Internet Message Access Protocol
(IMAP) login for E-mail Reader
161 UDP SNMP Network troubleshooting information
for the Call Processing Server (CPS)
servers
Using Simple Network Management
Protocol (SNMP) management soft-
ware with the CPS servers
162 UDP SNMP Network troubleshooting information
for the CPS servers
Using SNMP management software
with the CPS servers
389 TCP/UDP LDAP
•UC
•IVR
Database information
443 TCP SSL
Secure
Web
https
• System Manager
• Automatic Diagnostics Delivery
(ADD) feature on CPC and CPS
•EC
• System Manager
• File transfer for the ADD feature
• EC features
993 TCP IMAP IMAP client on EM (Outbound) SSL IMAP login for E-mail Reader
1433-1434 TCP/UDP SQL IVR database
2
Structured Query Language (SQL)
database
1800-1801 TCP/UDP General IVR MVEngine Service ports IP messaging
1
1863 TCP General UC Required when using Session Initi-
ated Protocol (SIP) server with UC
and Microsoft Passports
1900 TCP/UDP IVR IP Telephony; Requires additional
software
1
2427 UDP MGCP Media Gateway Control Protocol
(MGCP) Gateway
MGCP equipment
3001 UDP General Non ATM Call Processing Unit - CPU
(EAC CPU to CPS Server)
512 CPS communications port
between the CPS and EAC CPU
3307 TCP SQL IVR SQL database
3389 TCP Terminal
Services
•UC
• System Manager
Required for troubleshooting
3707 TCP Secure
Real-
Time
Connec-
tion
System Manager SIP Server
Table F-1. Port Assignments (Continued)
Port TCP/UDP
Port
Name
Inter-Tel Products Access to:
