Page F-23
Appendix F – Network Topology
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Port Usage Summary
APPENDICES
3986 TCP General CCS CCS Server
1
4000 TCP/UDP General
•CPS
• Between a CPS and Voice
Processing Unit (VPU)
• CT Gateway
3
• Desktop SoftPhone
• Attendant Console
•IVR
•UC
•EC
• Advanced communication plat-
form to external products, DB
Programming, System Open Archi-
tecture Interface (OAI), Diagnos-
tics Monitor, Station Message
Detail Recording (SMDR), and
Message Print
• IP sockets (used instead of RS232
ports)
• Nodes, CPS and CPC, or applica-
tions
1
4000 TCP General EM (Outbound) ASAI connection to the CPC/CPS
4001 UDP General ATM ELAN ATM ELAN; Port used by the ATM
system for communicating between
Redundant Servers
4444 UDP General VPU AvdapMon
1
4445 TCP General EM (Inbound/Outbound) Networking Provider
4567 TCP General UC UC communications for Client con-
nections
5000-5018 UDP General Interprize 3200 Call Control for VoIP traffic
1
5000-5099 TCP General UM (Inbound to EM) UM server inbound file transfers
5004-5069 UDP General
• IP devices
•IPC
• IPRC Networking
IP devices and IPRC Networking (IP
Random Voice Ports)
1
5004 UDP General
•IPRC
•IPC
• IP endpoints
4
Axxess Audio Stream Receive port
1
5004 UDP RTP
•IPRC
• IP Resource Allocation (IPRA)
• IP endpoints
Ports must be odd numbers
IP Voice
1
5005 UDP RTPC
•IPRC
•IPRA
• IP endpoints
Port must be odd numbers
IP Voice
1
5060 TCP/UDP SIP SIP Server Communications between the SIP
server and IPRC or SIP devices
5070 TCP General IP Networking TCP Call Control port
1
5100-5149 TCP General UM UM server outbound file transfers
Table F-1. Port Assignments (Continued)
Port TCP/UDP
Port
Name
Inter-Tel Products Access to:
