Page F-24
Appendix F – Network Topology
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Port Usage Summary
5444 TCP General EM (Inbound) Default Operations, Administration,
and Maintenance (OAM) Console
admin interface
5445 TCP General EM (Inbound) Default OAM Console event interface
5555-5556 TCP General IVR Point Server
5566 TCP General
• IP devices
•IPRC Networking
•IPC
• Inter-Tel 5000
IP terminal TCP Call Control port
1
5567 UDP General
• IP devices
•IPRC Networking
•IPC
• Inter-Tel 5000
IP terminal General Purpose port
1
5568 UDP General
•IPRC
•IPRA
• Inter-Tel 5000
Message server port for sending IP
diagnostic information from Axxess or
Inter-Tel 5000
1
5631 TCP General CPS Servers pcAnywhere for remote access
1
5632 UDP General CPS Servers pcAnywhere for remote access
1
6004 UDP General IP endpoints and Inter-Tel 5000
4
Inter-Tel 5000 Audio Stream Receive
Port
1
6004-6247 UDP General IP endpoints and Inter-Tel 5000
4
Inter-Tel 5000 pre-v2.0 Audio Steam
6004-6261 UDP General IP endpoints and Inter-Tel 5000
4
Inter-Tel 5000 v2.0 and later Audio
Stream for the Processor Module
(PM-1)
6604-6039 UDP General IP endpoints and Inter-Tel 5000
4
Inter-Tel 5000 v2.0 and later Audio
Stream for the Processor Expansion
Card (PEC-1)
7000 TCP General UM (Inbound to EM) UM server
7777 UDP General UM on VPU The UM clients
1
8080 TCP HTTP IP products and IP endpoints Programming information
1
8886 TCP SIP Server SIP Server
16384 UDP General Interprize 3200 Voice Traffic (VoIP)
Various
Ports
5
TCP/UDP General Third-party or custom applications Various features depending on the
product
1. The listed port numbers for these applications are the default values and can be changed in DB Programming.
2. The IVR can use other types of database engines where other network ports can be used.
3. CT Gateway has two programmable ports - one for communicating to the nodes and one for communicating to the applications. Both
of these ports are programmable and default to port 4000.
4. IP endpoints (Axxess/Eclipse IP PhonePlus and Model 8660) use port 5004 for audio. Newer IP endpoints (Model 86XX, excluding
the Model 8660) use port 6004 for audio.
5. Third-party products that interface with Inter-Tel products may use port numbers other than what are listed in this document.
Table F-1. Port Assignments (Continued)
Port TCP/UDP
Port
Name
Inter-Tel Products Access to:
