Inter-Tel AXXESS - Page 180

Page 2-112
Specifications
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Model 8520
Figure 2-15. Model 8520
NOTE: The buttons are shown as they appear in the default keymap configuration.
RING AND VOICE
VOLUME
CONTROLS
12-KEY
PUSHBUTTON
KEYPAD
RED HOLD BUTTON
MESSAGE
LAMP
FEATURE
BUTTONS
SPECIAL
BUTTON
FEATURE
BUTTONS
INTERNAL
SPEAKER
(underneath
handset)
HANDSFREE
MICROPHONE
(underneath edge)
HEARING AID-COMPATIBLE
(HAC) HANDSET
LCD WITH TWO
16-CHARACTER LINES
