Page 2-115
Specifications
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Model 8500
SPECIFICATIONS
2
Figure 2-18. Model 8500
NOTE: The buttons are shown as they appear in the default keymap configuration.
12-KEY
PUSHBUTTON
KEYPAD
HANDSFREE
MICROPHONE
RING AND VOICE
VOLUME CONTROLS
(underneath edge)
SPECIAL
BUTTON
RED HOLD
BUTTON
FEATURE
BUTTONS
FEATURE
BUTTONS
MESSAGE
LAMP
INTERNAL
SPEAKER
(underneath
handset)
HEARING AID-COMPATIBLE
(HAC) HANDSET
