Page 6-138
Programming
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
BRI Card Configuration
* Currently, the overlap sending/receiving protocols are supported with PRI Net 5 and BRI Net 3 switch
types, which are prevalent in the Europe and Mexico markets.
Diagnostics
3.114 The Diagnostics folders, located within each trunk port folder in DB Programming, are
used for troubleshooting. The following information appears:
• Hourly Display: Double-click on Hourly to see the number of errors that have occurred
during each hour for the past 24 hours.
• Daily Display: Double-click on Daily to see the number of errors that have occurred
during several 24-hour periods.
• Hourly Summary: The hourly summary shows the number of errors that have occurred
in the past hour.
• Daily Summary: The daily summary shows the number of errors that have occurred in
the past 24 hours.
Restart
Acknowledge
(T316)
120 1-255
seconds
The system initiates this timer when a Channel Restart message is sent.
The timer is terminated when the Restart Acknowledge is received from
the public network. If the Restart Acknowledge is not received before this
timer expires, the system sends a second Restart message to the public
network. If the timer expires a second time and a Restart Acknowledge
has not been received from the public network, the system idles the
respective channel.
Retransmit TE1
Request UI Mes-
sages (T202)
20 1-65535
tenths
Controls the amount of time the ISDN Data Link layer will wait for a
response from the network before it re-transmits a UI frame during the
TEI assignment procedure.
Resume
Acknowledge
(T318)
41-255
seconds
If the appropriate Resume response (Resume Acknowledge or Resume
Reject) is not received before this timer expires, the requesting system
sends a Release Request.
Re-Transmis-
sion (T200)
10 1-65535
tenths
This timer controls the amount of time the ISDN Data Link layer will wait
for an acknowledgment from the network before it transmits a frame
again.
Setup Request
Acknowledge
(T303)
41-255
seconds
If the appropriate Setup Request response (Alerting, Connect, Call Pro-
ceeding, Setup Acknowledge, or Release) is not received before this
timer expires, the requesting system sends another Setup Request or
clears the call.
Status Enquiry
(T322)
41-255
second
The system is expected to respond to the Network Status Enquiry within
this time interval. If the system does not respond before the timer expires,
the network will send a second Status Enquiry and will again expect the
system’s status response within this interval. Although the system does
not actively use this timer, it is provided as a reference to gauge the sys-
tem’s response.
Suspend
Acknowledge
(T319)
41-255
seconds
If the appropriate Suspend response (Disconnect, Release, Suspend
Acknowledge, or Suspend Reject) is not received before this timer
expires, the requesting system sends a Suspend Reject.
XID Request
(T204)
20 1-65535
tenths
This timer controls how long the ISDN Link Data layer will wait for an XID
response from the network before transmitting the XID Request again.
(XID parameter negotiation is not supported.)
Table 6-21: BRI Timers (Continued)
Timer
Default
Value
Range Purpose
