Page 2-80
Specifications
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Inter-Tel/DVK Analog Phones
E. INTER-TEL/DVK ANALOG PHONES
NOTE: Inter-Tel/DVK analog phones are not supported in Europe.
5.36 Refer to a version 7.0 or earlier Installation and Maintenance Manual for Inter-Tel/
DVK analog phone installation instructions. The following Inter-Tel/DVK analog models are
available:
• Inter-Tel/DVK 24-Line Phones (standard and display)
• Inter-Tel/DVK 12-Line Phones (standard and display)
• Inter-Tel/DVK 8-Line Phones (standard and display)
5.37 For illustrations of the phones, dimensions, features, etc. refer to a version 7.0 or earlier
Installation and Maintenance Manual.
F. DIGITAL DIRECT STATION SELECTION/BUSY LAMP FIELD (DSS/BLF) UNITS
5.38 The Inter-Tel system supports three types of DSS/BLF Consoles/Units. The unit used
depends on the phone.
• With Executone IDS Phones: IDS phones can be equipped with up to three 48-key
DSS Consoles. There can be a total of 80 IDS 48-key DSS Consoles on the system.
Each 48-key DSS Console requires an EKSC circuit.
NOTE: For details about the 48-key DSS/BLF Unit, see a version 7.0 or earlier Eclipse
Installation and Maintenance Manual.
• With Executive Display, Standard Display, Professional Display, and Associate Dis-
play Phones: PCDPM-equipped Executive Display, Professional Display, Standard
Display, and Associate Display Phones may be connected to up to four 60-key DSS/
BLF Units. There can a total of 20 of these 60-key DSS/BLF Consoles on the system.
Because each unit is powered by an AC transformer and is connected to the phone’s
PCDPM, the 60-key DSS/BLF Consoles do not require a DKSC or DKSC-16/DKSC-
16+ circuit that is separate from the phone. There is a 6-row model that is designed for
Executive Display and Standard Display Phones and a 12-row model that is designed
for Professional Display and Associate Display Phones
• With Model 8520 and Model 8560 Phones: PCDPM-equipped Model 8520 and
Model 8560 Phones may be connected to up to four 50-key DSS/BLF Units. There can
a total of 20 of these 50-key DSS/BLF Units on the system. Because each unit is pow-
ered by an AC transformer and is connected to the phone’s PCDPM, the 50-key DSS/
BLF Consoles do not require a DKSC or DKSC-16/DKSC-16+ circuit that is separate
from the phone
5.39 There are two types of DSS/BLF Units available. One is a 60-key model and the other
is a 50-key model. Although the 60-key, 6-row model is designed for Executive Display and
Standard Display Phones and the 50-key model is designed for Model 8520 or Model 8560
Phones, you can use either DSS/BLF Unit on any of these phones. Each single unit provides
one-button access to 50 or 60 extension numbers and/or other features/resources, while four
units provide access to 200 or 240 extension numbers and/or other features/resources. (See
page 3-202 for DSS/BLF Unit installation instructions.)
