Call Logging Displays on a Six-Line Display Endpoint
FEATURES
5
23.6 The entries are displayed from newest to oldest. After the list is full, the newest call is
moved to the front of the list and the oldest call entry is removed. The user can scroll through
all of the entries in the list via the user interface (see page 5-182).
A. CALL LOGGING DISPLAYS ON A SIX-LINE DISPLAY ENDPOINT
NOTE: At any menu level, you can press the asterisk ( ) button to cancel or return to the
previous menu, or press the pound/hash ( ) button to accept.
23.7 The following are examples of the call logging displays on a six-line endpoint:
• Idle Display. Six-line endpoints have an option on the idle menu to access the logs
directly. Note that the six-line display administrator endpoints no longer show “ADMIN
FEATURES” on the first line, but rather just “ADMIN” to make room for the
“MISSED XX” (where XX can be from 1-99) calls menu option on the right side of the
display (see page 5-182).
• The Main Menu. When the LOGS menu option is selected, the following display
appears.
• Call Log Display. When one of the call menu options (Missed=1, Received=2, or
Dialed=3) is selected in the main menu, a display similar to the one below appears. The
arrow (<< and >>) menu buttons at the bottom of the display only appear if there is
more than one entry in the list on a six-line display endpoint.
29999 JOHN DOE
1:53 FRI AUG 20
OUTGOING DND
DIRECTORY LOGS
OTHER FEATURES
Non-Admin Endpoint
29999 JOHN DOE
1:53 FRI AUG 20
ADMIN
OUTGOING DND
DIRECTORY LOGS
OTHER FEATURES
Admin Endpoint
LOG TYPE: MISS=1
RCV=2 DL=3 CLR=4
MISSED CALLS
RECEIVED CALLS
DIALED CALLS
CLEAR CALL LOGS
Or, “DIALLED CALLS” for European systems
JOHN DOE
4809619000
FR AUG 20 11:53A
DELETE DEL ALL
CALL NOW
<< >>
JANE DOE
x29999
FR AUG 20 11:53A
DELETE DEL ALL
CALL NOW
<< >>
OR
