Send documentation comments to mdsfeedback-doc@cisco.com
48-17
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 48 Configuring FCIP
Using the FCIP Wizard
Step 4 Click the ELP tab if it is not already selected. You see the FCIP ELP dialog box.
Checking Trunk Status
To check the trunk status for the FCIP interface on Device Manager, follow these steps:
Step 1 Make sure you are connected to a switch that contains an IPS module.
Step 2 Select FCIP from the IP menu.
Step 3 Click the Trunk Config tab if it is not already selected. You see the FCIP Trunk Config dialog box. This
shows the status of the interface.
Step 4 Click the Trunk Failures tab if it is not already selected. You see the FCIP Trunk Failures dialog box.
Launching Cisco Transport Controller
Cisco Transport Controller (CTC) is a task-oriented tool used to install, provision, and maintain network
elements. It is also used to troubleshoot and repair NE faults.
To launch CTC using Fabric Manager, follow these steps:
Step 1 Right-click an ISL carrying optical traffic in the fabric.
Step 2 Click Element Manager.
Step 3 Enter the URL for the Cisco Transport Controller.
Step 4 Click OK.
Launching Cisco Transport Controller
Cisco Transport Controller (CTC) is a task-oriented tool used to install, provision, and maintain network
elements. It is also used to troubleshoot and repair NE faults.
To launch CTC using Fabric Manager, follow these steps:
Step 1 Right-click an ISL carrying optical traffic in the fabric.
Step 2 Click Element Manager.
Step 3 Enter the URL for the Cisco Transport Controller.
Step 4 Click OK.
