Send documentation comments to mdsfeedback-doc@cisco.com
30-22
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 30 Configuring and Managing Zones
Zone Sets
Creating FC Aliases
To create an FC alias using Fabric Manager, follow these steps:
Step 1 Choose Zone > Edit Local Full Zone Database.
You see the Select VSAN dialog box.
Step 2 Select a VSAN and click OK.
You see the Edit Local Full Zone Database dialog box for the selected VSAN.
Step 3 Click Aliases in the lower left pane (see Figure 30-23). The right pane lists the existing aliases.
Figure 30-23 Creating an FC Alias
Step 4
Click the Insert icon to create an alias.
You see the Create Alias dialog box shown in Figure 30-24.
Figure 30-24 Create Alias Dialog Box
Step 5
Set the Alias Name and the pWWN.
Step 6 Click OK to create the alias.
Adding Members to Aliases
To add a member to an alias using Fabric Manager, follow these steps:
