Chapter 32 Configuring Fibre Channel Routing Services and Protocols

FSPF Interface Configuration

Figure 32-7 FSPF Database Information in the LSDB LSRs Tab

Step 3 Click Close to close the dialog box.

Viewing FSPF Statistics

To view FSPF statistics using Fabric Manager, follow these steps:

Step 1 Expand a Fabric, expand a VSAN, and then select FSPF in the Logical Domains pane.

You see the FSPF configuration dialog box.

Step 2 Click the Statistics tab.

You see the FSPF VSAN statistics in the Information pane (see Figure 32-8).

Figure 32-8 FSPF VSAN Statistics

Step 3 Click the Interface Statistics tab.
