Send documentation comments to mdsfeedback-doc@cisco.com
25-8
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 25 Configuring Domain Parameters
Domain IDs
Enabling Autoreconfiguration
To enable automatic reconfiguration in a specific VSAN (or range of VSANs) using Fabric Manager,
follow these steps:
Step 1 Expand Fabricxx > VSANxx and then select Domain Manager in the Logical Domains pane for the
fabric and VSAN that you want to enable automatic reconfiguration for.
You see the running configuration of the domain in the Information pane.
Step 2 Select the Configuration tab and check the Auto Reconfigure check box for each switch in the fabric
that you want to automatically reconfigure.
Step 3 Click the Apply Changes icon to save these changes.
Domain IDs
Domain IDs uniquely identify a switch in a VSAN. A switch may have different domain IDs in different
VSANs. The domain ID is part of the overall FC ID.
This section describes how to configure domain IDs and includes the following topics:
• About Domain IDs, page 25-8
• Specifying Static or Preferred Domain IDs, page 25-10
• About Allowed Domain ID Lists, page 25-11
• Configuring Allowed Domain ID Lists, page 25-11
• About CFS Distribution of Allowed Domain ID Lists, page 25-12
• Enabling Distribution, page 25-12
• Locking the Fabric, page 25-13
• Committing Changes, page 25-13
• Discarding Changes, page 25-13
• Clearing a Fabric Lock, page 25-14
• Displaying Pending Changes, page 25-14
• Displaying Session Status, page 25-15
• About Contiguous Domain ID Assignments, page 25-15
• Enabling Contiguous Domain ID Assignments, page 25-15
About Domain IDs
The configured domain ID can be preferred or static. By default, the configured domain ID is 0 (zero)
and the configured type is preferred.
Note The 0 (zero) value can be configured only if you use the preferred option.
