Chapter 7 Fabric Manager Web Client
Performance
Viewing Performance Information for GigE Ports
To view GigE ports using Fabric Manager Web Client, follow these steps:
Step 1 Click the Performance tab, and then click Ethernet.
You see the Ethernet tab window as shown in Figure 7-16.
Figure 7-16 Ethernet Tab
Step 2
Expand a fabric and select one of the VSANs to display the GigE ports in that VSAN.
Note There are variations to this procedure. In addition to these basic steps, you can also:
• Select the time range, and click Filter to filter the display.
• Select the name of a GigE port from the Name column to see a graph of the traffic across that GigE
port for the past 24 hours. You can change the time range for this graph by selecting it from the
drop-down list in the upper right corner.
Viewing Other Statistics
To view other statistics using Fabric Manager Web Client, follow these steps:
Step 1 Click the Performance tab, and then click Others.
You see the Others tab window as shown in Figure 7-17.
