Send documentation comments to mdsfeedback-doc@cisco.com
30-7
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 30 Configuring and Managing Zones
Using the Quick Config Wizard
Using the Quick Config Wizard
Note The Quick Config Wizard supports only switch interface zone members.
As of Cisco SAN-OS Release 3.1(1) and NX-OS Release 4.1(2), you can use the Quick Config Wizard
on the Cisco MDS 9124 Switch to add or remove zone members per VSAN. You can use the Quick
Config Wizard to perform interface-based zoning and to assign zone members for multiple VSANs using
Device Manager.
Note The Quick Config Wizard is supported on the Cisco MDS 9124 Fabric Switch, the Cisco MDS 9134
Fabric Switch, the Cisco Fabric Switch for HP c-Class BladeSystem, and the Cisco Fabric Switch for
IBM BladeCenter.
Caution The Quick Config Wizard can only be used on stand-alone switches that do not have any existing zoning
defined on the switch.
To add or remove ports from a zone and to zone only the devices within a specific VSAN using Device
Manager on the Cisco MDS 9124 Switch, follow these steps:
Step 1 Choose FC > Quick Config or click the Zone icon in the toolbar.
You see the Quick Config Wizard (see Figure 30-5) with all controls disabled and the Discrepancies
dialog box (see Figure 30-4), which shows all unsupported configurations.
Note You will see the Discrepancies dialog box only if there are any discrepancies.
