Send documentation comments to mdsfeedback-doc@cisco.com
29-17
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 29 Configuring Inter-VSAN Routing
Manual IVR Configuration
Step 4 Click the Apply Changes icon to activate the IVR topology.
Clearing the Configured IVR Topology
You can only clear manually created IVR VSAN topology entries from the configured database.
To clear the IVR topology using Fabric Manager, follow these steps:
Step 1 Expand All VSANs and then select IVR in the Logical Domains pane.
Step 2 Click the Control tab if it is not already displayed.
Step 3 Highlight the rows you want to delete from the IVR topology.
Step 4 Click the Delete Row icon to delete these rows from the IVR topology.
Step 5 Click the Apply Changes icon to delete the IVR topology.
Migrating from IVR Auto Topology Mode to Manual Mode
If you want to migrate the active IVR VSAN topology database from automatic mode to user-configured
mode, first copy the active IVR VSAN topology database to the user-configured IVR VSAN topology
database before switching modes.
To migrate from automatic mode to manual mode using Fabric Manager, follow these steps:
Step 1 Expand All VSANs and then select IVR in the Logical Domains pane.
You see the IVR configuration in the Information pane.
Figure 29-10 Action Tab
Step 2
Click the Action tab.
Step 3 Highlight the switch on which you want to disable auto topology mode.
Step 4 Uncheck the Auto Discover Topology check box (see Figure 29-10).
Step 5 Click the Apply Changes icon.
