Chapter 30 Configuring and Managing Zones
Zone Sets
Step 3 Select the members you want to add from the Fabric pane (see Figure 30-13) and click Add to Zone or
click the zone where you want to add members and click the Insert icon.
You see the Add Member to Zone dialog box shown in Figure 30-14.
Figure 30-14 Add Member to Zone Dialog Box
Note The Device Alias radio button is visible only if device alias is in enhanced mode. For more
information, see “Creating a Device Alias” section on page 31-6.
Step 4 Click the browse button and select a port name or check the LUN check box and click the browse button
to configure LUNs.
Step 5 Click Add to add the member to the zone.
Note When configuring a zone member, you can specify that a single LUN has multiple IDs depending
on the operating system. You can select from six different operating systems.
Zone Sets
This section describes zone sets and includes the following topics:
• About Zone Set Creation, page 30-16
• Activating a Zone Set, page 30-17
• Displaying Zone Membership Information, page 30-20
• About the Default Zone, page 30-20
• Configuring the Default Zone, page 30-21
