Chapter 32 Configuring Fibre Channel Routing Services and Protocols
FSPF Interface Configuration
Displaying the FSPF Database
The FSPF database for a specified VSAN includes the following information:
• Link State Record (LSR) type
• Domain ID of the LSR owner
• Domain ID of the advertising router
• LSR age
• LSR incarnation member
• Number of links
To display the FSPF database using Device Manager, follow these steps:
Step 1 Choose FC > Advanced > FSPF.
You see the FSPF dialog box shown in Figure 32-6.
Figure 32-6 FSPF Dialog Box in Device Manager
Step 2 Click the LSDB LSRs tab.
You see the FSPF database information shown in Figure 32-7.
