Send documentation comments to mdsfeedback-doc@cisco.com
20-22
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 20 Configuring Interfaces
Fibre Channel Interfaces
Displaying SFP Transmitter Types
To show the SFP types for an interface using Fabric Manager, follow these steps:
Step 1 Expand Switches > Interfaces and then select FC Physical. You see the interface configuration in the
Information pane.
Step 2 Click the Physical tab to see the transmitter type for the selected interface.
About Gathering Interface Statistics
You can use Fabric Manager or Device Manager to collect interface statistics on any switch. These
statistics are collected at intervals that you can set.
Gathering Interface Statistics
Note In Fabric Manager, you can collect interface statistics by expanding Switches > ISLs and selecting
Statistics from the Physical Attributes pane.
To gather and display interface counters using Device Manager, follow these steps:
Step 1 Right-click an interface and select Monitor.
You see the Interface Monitor dialog box.
Step 2 Set both the number of seconds at which you want to poll the interface statistics and how you want the
data represented in the Interval drop-down menus. For example, click 10s and LastValue/sec.
Step 3 Select any tab shown in Figure 20-11 to view those related statistics.
CWDM-1570 c1570
CWDM-1590 c1590
CWDM-1610 c1610
Table 20-5 SFP Transmitter Acronym Definitions (continued)
Definition Acronym
Standard transmitters defined in the GBIC specifications
