Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 29 Configuring Inter-VSAN Routing
Manual IVR Configuration
Step 7 If you did not enable IVR NAT, verify the transit VSAN or configure the transit VSAN if Fabric Manager
cannot find an appropriate transit VSAN.
Step 8 Set the IVR zone and IVR zone set.
Step 9 Verify all steps that Fabric Manager will take to configure IVR in the fabric.
Step 10 Click Finish if you want to enable IVR NAT and IVR topology and to create the associated IVR zones
and IVR zone set.
You see the Save Configuration dialog box. You can save the configuration of the master switch to be
copied to other IVR-enabled switches.
Step 11 Click Continue Activation, or you may click Cancel.
Step 12 Click Finish.
Note IVR NAT and auto-topology can be configured independently if you configure these features outside the
IVR Zone Wizard. See the “Manual IVR Configuration” section on page 29-9.
Manual IVR Configuration
You can configure IVR using the IVR tables in the Information pane in Fabric Manager. Use these tables
only if you are familiar with all IVR concepts. We recommend you configure IVR using the IVR Wizard.
Note Most tabs in the Information pane for features using CFS are dimmed until you click the CFS tab. The
CFS tab shows which switches have CFS enabled and shows the master switch for this feature. Once the
CFS tab is clicked, the other tabs in the Information pane are activated.
This section describes manually configuring IVR and includes the following topics:
• About IVR NAT and Auto Topology, page 29-10
• Configuring IVR NAT and IVR Auto Topology, page 29-11
• About AFIDs, page 29-11
• Configuring Default AFIDs, page 29-12
• Configuring Individual AFIDs, page 29-12
• About IVR Without IVR NAT or Auto Topology, page 23-23
• Configuring IVR Without NAT, page 29-14
• Manually Creating the IVR Topology, page 29-15
• Activating a Manually Configured IVR Topology, page 29-16
• Clearing the Configured IVR Topology, page 29-17
• Migrating from IVR Auto Topology Mode to Manual Mode, page 29-17
• About IVR Virtual Domains, page 29-18
• Configuring IVR Virtual Domains, page 29-18
• About Persistent FC IDs for IVR, page 29-19
