Send documentation comments to mdsfeedback-doc@cisco.com
15-14
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 15 Software Images
Maintaining Supervisor Modules
– Telnet sessions
– Schedule changes
– Switch cabling
– Addition or removal of physical devices
• Configure the FSPF timers to the default value of 20 seconds.
• If there are any CFS commits pending in the fabric, the upgrade is aborted.
• If there is a zone server merge in progress, the upgrade is aborted.
• Check whether there is sufficient space available in the system to load the new images using the
Software Install Wizard. At this point you need to either abort the upgrade or proceed with a
disruptive upgrade.
• On the Cisco MDS 18/4-port multiservice module, upgrades of the 4-Gigabit Ethernet ports for the
hybrid Supervisor 18/4 line card will be disruptive.
Performing a Nondisruptive Upgrade on a Fabric Switch
• Cisco MDS 9124 Multilayer Fabric Switch
• Cisco MDS 9134 Multlayer Fabric Switch
• Cisco MDS 9222i Multiservice Modular Switch
• Cisco Fabric Switch for HP c-Class BladeSystem
• Cisco Fabric Switch for IBM BladeCenter
You can use the Software Install Wizard to perform nondisruptive upgrades on Cisco MDS 9124 Fabric
Switches. See “Using the Software Install Wizard” section on page 15-8 for more information on using
the Sofware Install Wizard.
Caution It is recommended that you enable port-fast on the Ethernet interface of the Catalyst switch to which the
management interface of the fabric switch is connected. This is to avoid spanning-tree convergence time
on the Catalyst switch and packets from the fabric switch are forwarded immediately during the
nondisruptive upgrade.
Note When selecting images during the upgrade, ASM-SFN and SSI are not supported on the Cisco MDS
9124 Switch and the Cisco MDS 9134 Multilayer Fabric Switch.
Maintaining Supervisor Modules
This section includes general information about replacing and using supervisor modules effectively.
This section includes the following topics:
• Replacing Supervisor Modules, page 15-15
• Migrating from Supervisor-1 Modules to Supervisor-2 Modules, page 15-15
• Standby Supervisor Module Boot Variable Version, page 15-15
• Standby Supervisor Module Bootflash Memory, page 15-16
