Send documentation comments to mdsfeedback-doc@cisco.com
60-8
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 60 Monitoring Network Traffic Using SPAN
Configuring SPAN
Step 10 Close the two dialog boxes.
Editing SPAN Sources
To edit a SPAN source using Device Manager, follow these steps:
Step 1 Choose Interface > SPAN.
You see the SPAN dialog box.
Step 2 Click the Sources tab.
You see the dialog box shown in Figure 60-6.
Figure 60-6 SPAN Sources Tab
Step 3 Enter the VSAN list name in the VSAN List field.
Step 4 Click Edit Interface List.
You see the Source Interfaces dialog box.
Step 5 Click Create.
You see the Source Interfaces Interface Sources dialog box shown in Figure 60-7.
Figure 60-7 Source Interfaces Interface Sources Dialog Box
Step 6 Click the browse button to display the list of available FC ports.
Step 7 Choose a port and click OK.
Step 8 Click the direction (receive or transmit) you want.
Step 9 Click Create to create the FC interface source.
