Send documentation comments to mdsfeedback-doc@cisco.com
32-19
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 32 Configuring Fibre Channel Routing Services and Protocols
Default Settings
Step 1 Expand a fabric and select All VSANS.
You see the VSAN configuration in the Information pane.
Step 2 Select the Attributes tab.
You see the general VSAN attributes in the Information pane shown in Figure 32-16.
Figure 32-16 General VSAN Attributes
Step 3 Double-click the Network Latency field and change the value.
Step 4 Click Apply Changes to save these changes, or click Undo Changes to discard any unsaved changes.
Default Settings
Table 32-4 lists the default settings for FSPF features.
Ta b l e 32-4 Default FSPF Settings
Parameters Default
FSPF Enabled on all E ports and TE ports.
SPF computation Dynamic.
SPF hold time 0.
Backbone region 0.
Acknowledgment interval (RxmtInterval) 5 seconds.
Refresh time (LSRefreshTime) 30 minutes.
Maximum age (MaxAge) 60 minutes.
Hello interval 20 seconds.
Dead interval 80 seconds.
Distribution tree information Derived from the principal switch (root node).
