36-31
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 36 Configuring FICON
Port Swapping
Step 4 Click Open.
Copying FICON Configuration Files
To copy an existing FICON configuration file using Device Manager, follow these steps:
Step 1 Choose FICON > VSANs.
Step 2 Click the Files tab.
You see the FICON VSANs dialog box (see Figure 36-17).
Step 3 Click Create to create a FICON configuration file.
You see the Create FICON VSANs Files dialog box shown in Figure 36-18.
Figure 36-18 Create FICON VSANs Files Dialog Box in Device Manager
a. Select a VSAN ID for the FICON VSAN you want to configure.
b. Enter the file name and the description.
c. Click Create to create the file.
Step 4 Click Copy to copy the file to a new file.
Step 5 Click Apply to apply the FICON configuration file.
Port Swapping
The FICON port-swapping feature is only provided for maintenance purposes.
The FICON port-swapping feature causes all configurations associated with old-port-number and new
port-number to be swapped, including VSAN configurations.
Cisco MDS switches allow port swapping for nonexistent ports as follows:
• Only FICON-specific configurations (prohibit, block, and port address mapping) are swapped.
• No other system configuration is swapped.
• All other system configurations are only maintained for existing ports.
