25-22
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 25 Configuring Domain Parameters
Displaying fcdomain Statistics
Figure 25-14 Persistent FC ID Information in Fabric Manager
Step 3 Check the Purge check box for the switch that you want to purge persistent FC IDs on (see
Figure 25-14).
Step 4 Click the Apply Changes icon to save these changes.
Displaying fcdomain Statistics
Fabric Manager collects statistics for fcdomain and displays them in the Information pane.
To display fcdomain statistics using Fabric Manager, follow these steps:
Step 1 Expand Fabricxx > All VSANs and then select Domain Manager in the Logical Domains pane for the
fabric that you want to display statistics for.
You see the running configuration of the domain in the Information pane.
Step 2 Click the Statistics tab. You see the FC ID statistics in the Information pane.
Default Settings
Table 25-2 lists the default settings for all fcdomain parameters.
Table 25-2 Default fcdomain Parameters
Parameters Default
fcdomain feature Enabled.
Configured domain ID 0 (zero).
Configured domain Preferred.
autoreconfigure option Disabled.
contiguous-allocation option Disabled.
Priority 128.
Allowed list 1 to 239.
Fabric name 20:01:00:05:30:00:28:df.
