Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 22 Configuring Generation 2 and Generation 3 Switching Modules
Port Groups and Port Rate Modes
Port Rate Modes
In Generation 2 and Generation 3 modules, you can configure the port rate modes. The port rate mode
configuration is used to determine the bandwidth allocation for ports in a port group. Two port rate
modes are supported:
• Dedicated Rate Mode—A port is allocated required fabric bandwidth to sustain line traffic at the
maximum operating speed configured on the port. For more information, see the “Dedicated Rate
Mode” section on page 22-6
• Shared Rate Mode—Multiple ports in a port group share data paths to the switch fabric and share
bandwidth. For more information, see the “Shared Rate Mode” section on page 22-7.
Note In Generation 1 modules, you cannot configure the port rate modes. The mode is determined implicitly
based on the port mode and line card type.
DS-X9304-18K9
(MSM-18/4
Multiservice
module)
18-port 4-Gbps
Fibre Channel
switching module
with 4-Gigabit
Ethernet ports
6 12.8 4 Gbps
DS-X9112 12-port 4-Gbps
Fibre Channel
switching module
3 12.8 4 Gbps
DS-X9704 4-port 10-Gbps
Fibre Channel
switching module
1 10 10 Gbps
Generation 2 Fabric Switches
DS-C9134-K9
(Cisco MDS 9134
Fabric switch)
32-port 4-Gbps
Fabric switch
4164 Gbps
2-port 10-Gbps
Fabric switch
1 10 10 Gbps
DS-C9124K9
(Cisco MDS 9124
Fabric switch)
24-port 4-Gbps
Fabric switch
4164 Gbps
DS-C9222i-K9
(Cisco MDS 9222i
Multiservice
Modular switch)
18-port 4-Gbps 6 12.8 4 Gbps
1. A maximum of 4 ports (one per port group) in a 4/44-port 8-Gbps switching module can operate at 8 Gbps bandwidth in
dedicated or shared mode. All the other ports can operate at a maximum of 4 Gbps in shared mode or dedicated mode.
Table 22-2 Bandwidth and Port Groups for the Fibre Channel Modules and Fabric Switches
Part Number
Product Name/
Description
Number of Ports
Per Port Group
Bandwidth Per
Port Group
(Gbps)
Maximum
Bandwidth Per Port
(Gbps)
