Send documentation comments to mdsfeedback-doc@cisco.com
19-2
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 19 Managing Modules
About Modules
Supervisor Modules
Supervisor modules are automatically powered up and started with the switch.
• Cisco MDS 9513 Directors have two supervisor modules—one in slot 7 (sup-1) and one in slot 8
(sup-2). See Table 19-2. When the switch powers up and both supervisor modules come up together,
the active module is the one that comes up first. The standby module constantly monitors the active
module. If the active module fails, the standby module takes over without any impact to user traffic.
• Cisco MDS 9506 and Cisco MDS 9509 switches have two supervisor modules—one in slot 5 (sup-1)
and one in slot 6 (sup-2). See Table 19-2. When the switch powers up and both supervisor modules
come up together, the active module is the one that comes up first. The standby module constantly
monitors the active module. If the active module fails, the standby module takes over without any
impact to user traffic.
• Cisco MDS 9216i switches have one supervisor module that includes an integrated switching
module with 14 Fibre Channel ports and two Gigabit Ethernet ports.
• Cisco MDS 9200 Series switches have one supervisor module that includes an integrated 16-port
switching module.
Cisco MDS 9216 One module 1 2-slot chassis allows one optional
switching or services module in the
other slot.
Cisco MDS 9216A One module 1 2-slot chassis allows one optional
switching or services module in the
other slot.
Cisco MDS 9216i One module 1 2-slot chassis allows one optional
switching or services module in the
other slot.
Table 19-1 Supervisor Module Options (continued)
Product
Number of
Supervisor
Modules
Supervisor
Module Slot
Number
Switching and Services Module
Features
Table 19-2 Supervisor Module Terms and Usage
Module Terms Fixed or Relative Usage
module-7 and module-8
Fixed usage for
MDS 9513
module-7 always refers to the supervisor module in slot 7 and
module-8 always refers to the supervisor module in slot 8.
module-5 and module-6
Fixed usage for
MDS 9509 and
MDS 9506
module-5 always refers to the supervisor module in slot 5 and
module-6 always refers to the supervisor module in slot 6.
module-1
Fixed usage for
MDS 9200 series
module-1 always refers to the supervisor module in slot 1.
