Send documentation comments to mdsfeedback-doc@cisco.com

63-6

Cisco MDS 9000 Family Fabric Manager Configuration Guide

OL-17256-03, Cisco MDS NX-OS Release 4.x

Chapter 63 Configuring Fabric Configuration Servers

Default Settings

Figure 63-5 FCS Fabric Ports

Step 3 Click Refresh to update the display.

Default Settings

Table 63-1 lists the default FCS settings.

Ta b l e 63-1 Default FCS Settings

Parameters Default

Global checking of the platform name Disabled.

Platform node type Unknown.
