Send documentation comments to mdsfeedback-doc@cisco.com
26-10
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 26 Configuring and Managing VSANs
VSAN Configuration
Figure 26-6 VSAN Port Membership Details
• VSAN-based runtime (name server), zoning, and configuration (static routes) information is
removed when the VSAN is deleted.
• Configured VSAN interface information is removed when the VSAN is deleted.
Note The allowed VSAN list is not affected when a VSAN is deleted (see Chapter 24, “Configuring
Trunking”).
Any commands for a nonconfigured VSAN are rejected. For example, if VSAN 10 is not configured in
the system, then a command request to move a port to VSAN 10 is rejected.
Deleting Static VSANs
To delete a VSAN and its attributes using Fabric Manager, follow these steps:
Step 1 Select All VSANs from the Logical Domains pane.
The VSANs in the fabric are listed in the Information pane.
Step 2 Right-click the VSAN that you want to delete and select Delete Row from the drop-down menu (see
Figure 26-7).
Default
VSAN
fc1/1
fc1/2
VSAN 7
fc1/3
fc1/4
Isolated
VSAN
VSAN 12
fc1/5
fc1/6
Before
Default
VSAN
fc1/1
fc1/2
VSAN 7
fc1/3
fc1/4
Isolated
VSAN
fc1/5
fc1/6
VSAN 12
fc1/5
fc1/6
After
Switch 1 Switch 1
79947
