Send documentation comments to mdsfeedback-doc@cisco.com
63-3
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 63 Configuring Fabric Configuration Servers
Displaying FCS Discovery
Displaying FCS Discovery
To display FCS discovery information using Device Manager, follow these steps:
Step 1 Choose FC > Advanced > Fabric Config Server.
You see the Fabric Config Server dialog box shown in Figure 63-2.
Figure 63-2 Fabric Config Server Dialog Box
Step 1 Click the Discovery tab.
Step 2 Click Discover to rediscover the fabric, or click Refresh to update the display.
Displaying FCS Elements
To display FCS interconnect element information using Device Manager, follow these steps:
Step 1 Choose FC > Advanced > Fabric Config Server.
You see the Fabric Config Server dialog box.
Step 2 Click the Interconnect Elements tab.
You see the dialog box shown in Figure 63-3.
