Send documentation comments to mdsfeedback-doc@cisco.com
36-27
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 36 Configuring FICON
Configuring FICON Ports
Step 1 Choose FICON > VSANs.
Step 2 Select a VASAN ID and click Port Configuration.
You see the FICON Port Configuration dialog box (see Figure 36-14).
Step 3 Set the port prohibit configuration for the selected FICON VSANs.
Step 4 Click Apply to save these changes.
Assigning a Port Address Name
Note To view the latest FICON information, you must click the Refresh button. See the “Automatically
Saving the Running Configuration” section on page 36-23.
To assign a port address name in Device Manager, follow these steps:
Step 1 Choose FICON > VSANs.
Step 2 Select a VSAN ID and click Port Configuration.
You see the FICON Port Configuration dialog box (see Figure 36-14).
Step 3 Enter the Port Configuration information.
Step 4 Click Apply to save the configuration information.
About RLIR
The Registered Link Incident Report (RLIR) application provides a method for a switch port to send an
Link Incident Record (LIR) to a registered Nx port. It is a highly available application.
When an LIR is detected in FICON-enabled switches in the Cisco MDS 9000 Family from a RLIR
Extended Link Service (ELS), the switch sends that record to the members in its Established Registration
List (ERL).
In case of multi-switch topology, a Distribute Registered Link Incident Record (DRLIR) Inter-Link
Service (ILS) is sent to all reachable remote domains along with the RLIR ELS. On receiving the DRLIR
ILS, the switch extracts the RLIR ELS and sends it to the members of the ERL.
The Nx ports interested in receiving the RLIR ELS send the Link Incident Record Registration (LIRR)
ELS request to the management server on the switch. The RLIRs are processed on a per-VSAN basis.
The RLIR data is written to persistent storage when you copy the running configuration to the startup
configuration.
Displaying RLIR Information
To view RLIR information using Device Manager, follow these steps:
