52-3
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 52 Configuring IP Storage
Supported Hardware
Step 2 Open the Switches folder and select Hardware in the Physical Attributes pane.
You see the status for all modules in the switch in the Information pane.
IPS Module Upgrade
Caution A software upgrade is only disruptive for the IPS module. The NX-OS software continues to support
nondisruptive software upgrades for Fibre Channel modules in the switch and for the switch itself.
IPS modules use a rolling upgrade install mechanism where each module in a given switch can only be
upgraded in sequence. To guarantee a stable state, each IPS module in a switch requires a 5-minute delay
before the next IPS module is upgraded.
MPS-14/2 Module Upgrade
Caution A software upgrade is only partially disruptive for the MPS-14/2 module. The NX-OS software
continues to support nondisruptive software upgrades for Fibre Channel modules in the switch and for
the switch itself.
The MPS-14/2 modules have 14 Fibre Channel ports (nondisruptive upgrade) and 2 Gigabit Ethernet
ports (disruptive upgrade). MPS-14/2 modules use a rolling upgrade install mechanism for the two
Gigabit Ethernet ports where each module in a given switch can only be upgraded in sequence. To
guarantee a stable state, each MPS-14/2 module in a switch requires a 5-minute delay before the next
module is upgraded.
Supported Hardware
You can configure the FCIP and iSCSI features using one or more of the following hardware:
• IPS-4 and IPS-8 modules (refer to the Cisco MDS 9200 Series Hardware Installation Guide or the
Cisco MDS 9500 Series Hardware Installation Guide for more information)
• MPS-14/2 module (refer to the Cisco MDS 9200 Series Hardware Installation Guide or the Cisco
MDS 9500 Series Hardware Installation Guide for more information).
Note In both the MPS-14/2 module and the Cisco MDS 9216i integrated supervisor module, the port
numbering differs for the Fibre Channel ports and the Gigabit Ethernet ports. The Fibre Channel
ports are numbered from 1 through 14 and the Gigabit Ethernet ports are numbered 1 and 2.
• Cisco MDS 9216i Switch (refer to the Cisco MDS 9200 Series Hardware Installation Guide).
