Chapter 19 Managing Modules
Identifying Module LEDs
Step 3 Click the Card Module Config tab.
Step 4 Select off from the drop-down list in the row for the module(s) you want to power off.
Step 5 Click the Apply Changes icon.
Note To power on a module, repeat Steps 1-4 but select on in Step 3.
Identifying Module LEDs
Table 19-5 describes the LEDs for the Cisco MDS 9200 Series integrated supervisor modules.
Table 19-5 LEDs for the Cisco MDS 9200 Series Supervisor Modules
LED Status Description
Status Green All diagnostics pass. The module is operational (normal initialization sequence).
Orange One of the following applies:
The module is booting or running diagnostics (normal initialization sequence).
The inlet air temperature of the system has exceeded the maximum system
operating temperature limit (a minor environmental warning). To ensure
maximum product life, you should immediately correct the environmental
temperature and restore the system to normal operation.
Red One of the following applies:
The diagnostic test failed. The module is not operational because a fault occurred
during the initialization sequence.
The inlet air temperature of the system has exceeded the safe operating
temperature limits of the card (a major environmental warning). The card has
been shut down to prevent permanent damage. The system will be shut down
after two minutes if this condition is not cleared.
Speed On 2-Gbps mode and beacon mode disabled.
Off 1-Gbps mode and beacon mode disabled.
Flashing Beacon mode enabledSee the “Identifying the Beacon LEDs” section on
page 20-19.
Link Solid green Link is up.
Solid
yellow
Link is disabled by software.
Flashing
yellow
A fault condition exists.
Off No link.
