Send documentation comments to mdsfeedback-doc@cisco.com
19-10
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 19 Managing Modules
Identifying Module LEDs
Table 19-6 describes the LEDs for the Cisco MDS 9200 Series interface module.
Table 19-7 describes the LEDs for the 16-port and 32-port switching modules, and the 4-port, 12-port,
24-port, and 48-port Generation 2 switching modules.
Table 19-6 LEDs on the Cisco MDS 9200 Series Interface Module
LED Status Description
Status Green All diagnostics pass. The module is operational (normal initialization
sequence).
Orange One of the following applies:
The module is booting or running diagnostics (normal initialization
sequence).
The inlet air temperature of the system has exceeded the maximum system
operating temperature limit (a minor environmental warning). To ensure
maximum product life, you should immediately correct the environmental
temperature and restore the system to normal operation.
Red One of the following applies:
The diagnostic test failed. The module is not operational because a fault
occurred during the initialization sequence.
The inlet air temperature of the system has exceeded the safe operating
temperature limits of the card (a major environmental warning). The card
has been shut down to prevent permanent damage.
System Green All chassis environmental monitors are reporting OK.
Orange One of the following applies:
The power supply failed or the power supply fan failed.
Incompatible power supplies are installed.
The redundant clock failed.
Red The temperature of the supervisor module exceeded the major threshold.
MGMT 10/100
Ethernet Link
LED
Green Link is up.
Off No link.
MGMT 10/100
Ethernet
Activity LED
Green Traffic is flowing through port.
Off No link or no traffic.
