48-39

Cisco MDS 9000 Family Fabric Manager Configuration Guide

OL-17256-03, Cisco MDS NX-OS Release 4.x

Chapter 48 Configuring FCIP

Default Settings

Control TCP and data connection No packets are transmitted

TCP congestion window monitoring Enabled

Burst size 50 KB

TCP connection mode Active mode is enabled

special-frame Disabled

FCIP timestamp Disabled

acceptable-diff range to accept packets +/– 2000 msec

B port keepalive responses Disabled

Write acceleration Disabled

Tape acceleration Disabled

Table 48-6 Default FCIP Parameters (continued)
