Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 2 Installing Cisco MDS NX-OS and Fabric Manager
Running Fabric Manager Behind a Firewall
• On a Windows desktop, uncomment the following in the FabricManager.bat or DeviceManager.bat
file in the C:\Program Files\Cisco Systems\MDS9000\bin directory:
rem JVMARGS=%JVMARGS% -Dsnmp.localport=9001
• On a UNIX desktop, uncomment the following in the FabricManager.sh or DeviceManager.sh file
in the $HOME/.cisco_mds9000/bin directory:
# JVMARGS=$JVMARGS -Dsnmp.localport=9001
In Fabric Manager Release 3.2(1) or later, Fabric Manager Client initiates communication with Fabric
Manager Server on the port 9099 for Java Naming Directory and Interface (JNDI) lookup. Fabric
Manager Server redirects the client to 1098 and JBoss directs the request to the appropriate service.
Fabric Manager Server proxy services uses a configurable TCP port (9198 by default) for SNMP
communications between the Fabric Manager Client or Device Manager and Fabric Manager Server.
The Fabric Manager Server component requires two predictable TCP ports to be opened on the firewall
for an incoming connection:
• server.port = 9099
• server.data.port = 9100
As long as these two ports are open, Fabric Manager Client can connect to the server. Other TCP ports
connected to Fabric Manager Client are initiated by the server, which is behind the firewall.
The following table lists all ports used by Fabric Manager applications:
Communication
Type
Port(s) Used
Used by All Applications
SSH Port 22 (TCP)
Telnet Port 23 (TCP)
HTTP Port 80 (TCP)
TFTP Port 69 (UDP)
SNMP Port 161 (UDP)
Syslog Port 514 (UDP)
Used by Fabric Manager Server and Performance Manager
SNMP_TRAP Port 2162 (UDP)
SNMP Picks a random free local port (UDP) or 9198 (TCP) if SNMP proxy is enabled.
Can be changed in server.properties.
Java RMI Ports 9099, 9100 (TCP)
Used by Fabric Manager Client
SNMP Picks a random free local port (UDP) if SNMP proxy is enabled. Can be changed
with the client -Dsnmp.localport option.
Java RMI Picks a free local port between 19199 and 19399 (TCP). Can be changed with
the client -Dclient.portStart and -Dclient.portEnd options. For example,
-Dclient.portStart = 19199 -Dclient.portEnd = 19399.
Used by Device Manager
