62-8
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 62 Configuring Call Home
Destination Profiles
• Profile name—A string that uniquely identifies each user-defined destination profile and is limited
to 32 alphanumeric characters. The format options for a user-defined destination profile are full-txt,
short-txt, or XML (default).
• Destination address—The actual address, pertinent to the transport mechanism, to which the alert
should be sent.
• Message formatting—The message format used for sending the alert (full text, short text, or XML).
To configure predefined destination profile messaging options using Fabric Manager, follow these steps:
Step 1 Expand Switches, expand Events, and select Call Home in the Physical Attributes pane.
Step 2 Click the Profiles tab in the Information pane.
You see the Call Home profiles for multiple switches shown in Figure 62-3.
Figure 62-3 Call Home Profiles for Multiple Switches
Step 3 Set the profile name, message format, message size, and severity level.
Step 4 Click in the Alert Groups column and select or remove an alert group.
Step 5 Click the Apply Changes icon to create this profile on the selected switches.
To configure a new destination-profile (and related parameters) using Fabric Manager, follow these
steps:
Step 1 Expand Switches, expand Events, and select Call Home in the Physical Attributes pane.
Step 2 Click the Profiles tab in the Information pane.
You see Call Home profiles for multiple switches.
Figure 62-4 Call Home Profiles for Multiple Switches
Step 3 Click the Create Row icon to add a new profile.
Step 4 Set the profile name, message format, size, and severity level.
Step 5 Click an alert group and select each group from the drop-down list that you want sent in this profile.
