Other
Green Square with Mode (e.g., F, T, TE, U/I for
FICON)
Port up.
Orange Square with Mode Trunk incomplete.
Orange Cross Ols or Nos received.
Brown Square Port is administratively down.
Light Gray Square Port is not manageable.
Red Cross HardwareFailure/LoopbackDiagFailure/LinkFail
ure
Red Square Any other kind of configuration failure.
No Square or Black Square Port not yet configured.
Ta b l e 67-2 Device Manager Tooltip Definitions
Tooltip Definition
adminDown The port is administratively down.
bitErrRTThresExceeded Bit error rate too high.
bundleMisCfg Misconfiguration in PortChannel membership
detected.
channelAdminDown This port is a member of a PortChannel and that
PortChannel is administratively down.
channelConfigurationInProgress This port is undergoing a PortChannel
configuration.
channelOperSuspended This port is a member of a PortChannel and its
operational parameters are incompatible with the
PortChannel parameters.
deniedDueToPortBinding Suspended due to port binding.
domainAddrAssignFailureIsolation The elected principal switch is not capable of
performing domain address manager functions so
no Nx_port traffic can be forwarded across
switches, hence all Interconnect_Ports in the
switch are isolated.
domainInvalidRCFReceived Invalid RCF received.
domainManagerDisabled Domain manager is disabled.
domainMaxReTxFailure Domain manager failure after maximum retries.
domainOtherSideEportIsolation The peer E port is isolated.
domainOverlapIsolation There is a overlap in domains while attempting to
connect two existing fabrics.
elpFailureClassFParamErr Isolated for ELP failure due to class F parameter
error.
Table 67-1 Fabric Manager and Device Manager Color Definitions (continued)
Fabric Manager Color Definition
