Send documentation comments to mdsfeedback-doc@cisco.com
5-29
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 5 Fabric Manager Client
Fabric Manager Client Quick Tour: Admin Perspective
Figure 5-10 Edit User Defined Group Dialog Box
Step 2 Enter a group name in the Name field.
Step 3 Use the arrows to move additional switches or end ports from the Available column to the Selected
column.
Step 4 Click OK to save the group.
To add a switch or end port to an existing group in Fabric Manager, follow these steps:
Step 1 Right-click a switch or end device and select Group > Add To > YourGroupName.
You see the Edit User Defined Group dialog box (see Figure 5-10).
Step 2 Use the arrows to move additional switches or end ports from the Available column to the Selected
column.
Step 3 Click OK to save the updated group.
To filter the display by a group you have created, follow these steps:
Step 1 Expand the Groups folder in the Logical Domains pane.
You see the list of groups that you have created as shown in Figure 5-11.
Figure 5-11 Group Highlighted in Fabric Pane Map
Step 2 Click the name of the group that you want to filter.
