Send documentation comments to mdsfeedback-doc@cisco.com
20-31
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 20 Configuring Interfaces
Default Settings
Step 1 Expand Switches > Interfaces and then select Management.
Figure 20-14 General Management Tab
Step 2
Click Create Row.
You see the Create Interface dialog box (see Figure 20-15).
Figure 20-15 Create Interface Dialog Box
Step 3
Select the switch and VSAN ID for which you want to configure a VSAN interface.
Note You can only create a VSAN interface for an existing VSAN. If the VSAN does not exist, you
cannot create a VSAN interface for it.
Step 4 Set IPAddress/Mask to the IP address and subnet mask for the new VSAN interface.
Step 5 Click Create to create the VSAN interface or click Close to close the dialog box without creating the
VSAN interface.
Default Settings
Table 20-7 lists the default settings for interface parameters.
