28-6
Cisco MDS 9000 Family Fabric Manager Configuration Guide
OL-17256-03, Cisco MDS NX-OS Release 4.x
Chapter 28 Creating Dynamic VSANs
DPVM
Note You must click on the CFS tab inorder to activate the other tabs
Step 3 Click the Config Database tab and then click the Create Row to insert a new entry.
You see the Create Config Database dialog box shown in Figure 28-6.
Figure 28-6 Create Config Database
Step 4
Choose an available WWN and VSAN combination or fill in the pWWN and Login VSAN fields.
Step 5 Click Create to save these changes in the config or pending database or click Close to discard any
unsaved changes.
Step 6 Click the CFS tab and select the Config Action drop-down menu for the master database.
You see the options shown in Figure 28-7.
Figure 28-7 Config Action Drop-down Menu
Step 7 Select commit from the drop-down menu to distribute these changes or abort to discard the changes.
