Chapter 36 Configuring FICON
FICON Port Numbering
Table 36-1 Default FICON Port Numbering in the Cisco MDS 9000 Family
Product
Slot
Number
Implemented Port Allocation
Unimplemented
Ports NotesTo Ports To PortChannel/FCIP
Cisco MDS
9200 Series
Slot 1 0 through 31 64 through 89 90 through 253
and port 255
Similar to a switching module.
Slot 2 32 through 63
Cisco MDS
9222i Series
Slot 1 0 through 31 64 through 89 90 through 253
and port 255
The first 4, 12, 16, or 24 port
numbers in a 4-port, 12-port,
16-port, or 24-port module are
used and the rest remain
unused. Extra 16 ports on
48-port modules are not
allocated numbers.
Slot 2 32 through 63
Cisco MDS
9506 Director
Slot 1 0 through 31 128 through 153 154 through 253
and port 255
Supervisor modules are not
allocated port numbers.
Slot 2 32 through 63
Slot 3 64 through 95
Slot 4 96 through 127
Slot 5 None
Slot 6 None
Cisco MDS
9134 Director
Slot 1 0 through 33 34 through 59 60 through 253
and port 255
Cisco MDS
9509 Director
Slot 1 0 through 31 224 through 249 250 through 253
and port 255
The first 4, 12, 16, or 24 port
numbers in a 4-port, 12-port,
16-port, or 24-port module are
used and the rest remain
unused. Extra 16 ports on
48-port modules are not
allocated port numbers.
Slot 2 32 through 63
Slot 3 64 through 95
Slot 4 96 through 127
Slot 5 None Supervisor modules are not
allocated port numbers.
Slot 6 None
Slot 7 128 through 159 The first 4, 12, 16, or 24 port
numbers are used for a 4-port,
12-port,16-port, or 24-port
module and the rest remain
unused. Extra 16 ports on
48-port modules are not
allocated port numbers.
Slot 8 160 through 191
Slot 9 192 through 223
