Cisco MDS 9000 Family Fabric Manager Configuration Guide

OL-17256-03, Cisco MDS NX-OS Release 4.x

Chapter 41 Configuring RADIUS and TACACS+

Default Settings

RADIUS server timeout 1 (one) second

RADIUS server retries Once

RADIUS server directed requests Disabled

TACACS+ Disabled

TACACS+ servers None configured

TACACS+ server timeout 5 seconds

TACACS+ server directed requests Disabled

AAA server distribution Disabled

Accounting log size 250 KB

Table 41-2 Default Switch Security Settings (continued)

Parameters Default
