Send documentation comments to mdsfeedback-doc@cisco.com

43-21

Cisco MDS 9000 Family Fabric Manager Configuration Guide

OL-17256-03, Cisco MDS NX-OS Release 4.x

Chapter 43 Configuring Certificate Authorities and Digital Certificates

Example Configurations

Step 5 Select the Base-64 encoded X.509 (CER) on the Certificate Export Wizard dialog box and click Next.

Step 6 Enter the destination file name in the File name: text box on the Certificate Export Wizard dialog box

and click Next.
