Dell PowerConnect 8024 Cli Reference Guide

168 ACL Commands
ACL41 1
show mac access-list
Use the show mac access-list command in Privileged EXEC mode to display a MAC access list
and all of the rules that are defined for the ACL.
Syntax
show mac access-list name
• name — Identifies a specific MAC access list to display.
Default Configuration
This command has no default configuration
Command Mode
Privileged EXEC mode
User Guidelines
This command has no user guidelines.
Example
The following example displays a MAC access list and all associated rules.
console#show mac access-list DELL123
The command output provides the following information:
Fields Description
MAC ACL Name The name of the MAC access list.
Rules The number of user-configured rules defined for the MAC ACL.
The implicit 'deny all' rule defined at the end of every MAC ACL is
not included.
Interfaces Displays the list of interfaces (unit/port) to which the MAC ACL is
attached in a given direction.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
