Dell PowerConnect 8024 Cli Reference Guide

IPv6 Routing Commands 687
Version........................................ 3
Num of Multicast Groups........................ 0
Unsolicited Report Interval.................... 1
Querier IP Address on Proxy Interface.......... fe80::1:2:5
Older Version 1 Querier Timeout................ 00:00:00
Proxy Start Frequency...........................1
show ipv6 mld-proxy groups
Use the show ipv6 mld-proxy groups command to display information about multicast groups
that the MLD Proxy reported.
Syntax
show ipv6 mld-proxy groups
Default Configuration
There is no default configuration for this command.
Command Mode
Privileged EXEC
User Guidelines
The following parameters are displayed by this command:
Interface The MLD Proxy interface.
Group Address The IP address of the multicast group.
Last Reporter The IP address of the host that last sent a membership report for the current group
on the network attached to the MLD-Proxy interface (upstream interface).
Up Time (in secs) The time elapsed in seconds since last created.
Member State Possible values are:
• Idle_Member—The interface has responded to the latest group membership query
for this group.
• Delay_Member—The interface is going to send a group membership report to
respond to a group membership query for this group.
Filter Mode Possible values are Include or Exclude.
Sources The number of sources attached to the multicast group.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
