Dell PowerConnect 8024 Cli Reference Guide

IP Helper Commands 611
User Guidelines
Field Descriptions:
Example
show ip helper-address
IP helper is enabled
Interface UDP Port Discard Hit Count Server Address
--------------- ----------- -------- ---------- ---------------
vlan 100 dhcp No 10 10.100.1.254
10.100.2.254
vlan 101 any Yes 2
any dhcp No 0 10.200.1.254
show ip helper statistics
Use the show ip helper statistics command to display the number of DHCP and other UDP
packets processed and relayed by the UDP relay agent.
Syntax
show ip helper statistics
Default Configuration
This command has no default configuration.
Interface The relay configuration is applied to packets that arrive on this interface. This field
is set to “any” for global IP helper entries.
UDP Port The relay configuration is applied to packets whose destination UDP port is this
port. Entries whose UDP port is identified as “any” are applied to packets with the
destination UDP ports listed in Table 4.
Discard If “Yes”, packets arriving on the given interface with the given destination UDP port
are discarded rather than relayed. Discard entries are used to override global IP
helper address entries which otherwise might apply to a packet.
Hit Count The number of times the IP helper entry has been used to relay or discard a packet.
Server Address The IPv4 address of the server to which packets are relayed.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
