Managed Switch CLI Manual, Release 8.0.3
Routing Commands 4-7
v1.0, July 2010
show arp brief
This command displays the brief Address Resolution Protocol (ARP) table information.
show arp switch
This command displays the contents of the switch’s Address Resolution Protocol (ARP) table.
MAC Address The hardware MAC address of that device.
Interface The routing unit/slot/port associated with the device ARP entry.
Type The type that is configurable. The possible values are Local, Gateway, Dynamic and
Static.
Age The current age of the ARP entry since last refresh (in hh:mm:ss format )
Format show arp brief
Mode Privileged EXEC
Term Definition
Age Time
(seconds)
The time it takes for an ARP entry to age out. This value is configurable. Age time is
measured in seconds.
Response Time
(seconds)
The time it takes for an ARP request timeout. This value is configurable. Response time is
measured in seconds.
Retries The maximum number of times an ARP request is retried. This value is configurable.
Cache Size The maximum number of entries in the ARP table. This value is configurable.
Dynamic Renew
Mode
Displays whether the ARP component automatically attempts to renew dynamic ARP
entries when they age out.
Total Entry
Count Current /
Peak
The total entries in the ARP table and the peak entry count in the ARP table.
Static Entry
Count Current /
Max
The static entry count in the ARP table and maximum static entry count in the ARP table.
Format show arp switch
Mode Privileged EXEC
Term Definition
