Managed Switch CLI Manual, Release 8.0.3
Quality of Service (QoS) Commands 8-17
v1.0, July 2010
match protocol
This command adds to the specified class definition a match condition based on the value of the IP
Protocol field in a packet using a single keyword notation or a numeric value notation.
To specify the match condition using a single keyword notation, the value for <protocol-
name> is one of the supported protocol name keywords. The currently supported values are:
icmp, igmp, ip, tcp, udp. A value of ip matches all protocol number values.
To specify the match condition using a numeric value notation, the protocol number is a standard
value assigned by IANA and is interpreted as an integer from 0 to 255.
Note: This “free form” version of the IP DSCP/Precedence/TOS match specification
gives the user complete control when specifying which bits of the IP Service Type
field are checked.
Default none
Format match ip tos <tosbits> <tosmask>
Mode Class-Map Config
Note: This command does not validate the protocol number value against the current list
defined by IANA.
Default none
Format match protocol {<protocol-name> | <0-255>}
Mode Class-Map Config
Ipv6-Class-Map Config
